◆FDW系列是一款專用型的滑動開關，也可推拉并芙或推撥并關，應用于小電流的電動工具或家用電器上，如：直流充電電鉆、燙發器等。
◆FDW seriesarespeciai typesiidesWitches, commoniy forusedin Low current Power-tools or home appliances, such as DCCordless Drill, Hair iron, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
◆單極三檔位Single Pole 3 Position (SP3P)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命E lectrical life endurance≥5E4
→最大電流 Max. current at 250V4A →最大電流 Max. current at 127V8A →接觸電阻 Contact resistance30m Ohm
→絕緣電阻 lnsulation resistance7M Ohm →基本介電強度 Dielectric strength of function500V →環境溫度 Ambient temperature-25℃~125℃ →阻燃等級 FlammabilityUL94V-0 →適用于II類防護器具 Suitable for appliances of protection class II
